MOBILE HOME PARK DISTRIBUTION CENTER

• EEMAC 3R enclosure for indoor/outdoor use

• Specifically designed as a heavy duty package meter power distribution center fully prewired complete with separate individual sections for TV and TEL

• 80"H x 62"W x 30"D - Parks Green

• Service entrance rated fused main

• 120/240V single phase complete with 125A "cold meter" sockets (optional to 200A) and breakers

• Front power section complete with 3 point padlockable, double hinged door

• Rear 7" TV & TEL sections complete with plywood backpan & three clasps

• Open bottom for cable entry - easy access style

• Flange on bottom turned in 3" all around complete with 4" snow kick

• Safety soft, machine formed corners on doors and overhanging driphood complete with cross-brake style roof and lifting hooks on top

OPTION

• Rear mount CDP and lifting control panel

NOTE

• Always consult local utilities for approval prior to ordering

• PEC section not available with hydro pull box

• Meter sockets & breakers are 1PH, 4 jaw, 10kAIC

• 5 & 7 jaw 3 pole breakers & 150A & 200A meter sockets are available (consult factory for sizing)

• Available in 800A models
