ROOF MATE ROOFTOP POWER PEDESTAL

• Specifically designed as a base mounted pedestal of maintenance free design complete with receptacle for specific maintenance of equipment located on rooftop locations (see CEC Rule #26-710d&e)

• 40” Or 44” high x 7” wide x 6” deep pedestal body complete with 10” x 10” screw-on galvanized base plate. Tall body allows for various roof insulation thickness

• 10.5” High removable front lower skirt to allow for membrane wrap installation

• Base is designed for easy fastening with various sized bolts (3/4” hole) or self tapping type screws as used by roofers

• Safety soft machine formed corners on hood for ultimate safety & soft European appearance

• ASA 61 Grey powder coat finish over galvanized steel, tunnel style body for durable assembly

• Devices are vertically fitted complete with back box, Model #DR45-RV-1 Handy Hood, & weatherproof cover to meet CEC Rule #26-708 for receptacles exposed to the weather

• Lower cavity is designed to fit with roofer gum ring/box & accepts insulation & sealant to support roofing seal to membrane

• CSA certified pedestal & assembly

Notes

• Back box complete with 3/4” threaded hub & model #DR45-RV-1 Handy Hood supplied & installed by Dandy

• Device & weatherproof cover supplied & installed by others (or optionally by Dandy)

• 10.5” High standard skirt size is to accommodate most standard installations. Confirm acceptance depending on site conditions.

• Taller skirt option is available

Read more in the New Product Bulletin and Product PDF
