DANDY LOADMISER™ ENERGY DIVIDER CONTROLLER
EEMAC 3R enclosure
Specifically designed as a load saving device, to be used where non-essential load is connected to an essential load circuit
Load saver cuts off power to the non-essential circuit only. Reducing load saves service upgrades
Adjustable 5 to 50 Amp of the circuit upstream rating
Easy to install for new and existing installations, simply connect in series of the existing load
Optional time of day clock prevents non-essential load from operation on/off hour, increasing energy savings and allowing non-essential load to operate on/off time energy availability
Sensing has adjustable 5 to 50 second time delay action to prevent rapid load cycling. Sensing is on only L1. To avoid nuisance tripping if loads are unbalanced add second phase current sensor option
White powder coat finish
CSA certified assembly
Options
Large capacity control to 600A, 600V
Dual line sensing - recommended when unbalanced loads could be encountered
Time clock for interval operation of load contactor eg. time of day
Extra large body sized 18" x 14" x 5"
Loadside branch circuit breaker on essential circuit or non essential circuit
Remote control output
Split CT design
Note
Refer to CEC Rule #’s 8-106 (4), (10) and (11), 8-500, and 12-3022 (4)
