COMBINATION UTILITY METER SOCKET/MCB

• EEMAC 3R enclosure

• Unique design allows for either hot or cold metering with line or load style service entrance rated main breaker. This combination design is ideal for adapting to specific utility requirements e.g., line side MCB for 480V and 600V systems or load side MCB for 208V systems. Available in single phase or three phase systems

• Preassembled CSA certified compact design allows for easy field installation

• Bottom feed and bottom exit body. Suitable for Cu/Al conductors

• Line type meter socket complete with sealing ring

• Padlockable door over bottom breaker cell adds to excellent security, vandal resistance, and enhanced appearance

• ASA 61 grey weatherproof assembly

• Fully CSA certified

Options

• 5th jaw for 208V network

• Insulated neutral in meter socket

• #BS2TCVFA meter socket complete with (1) #6-350 or (2)#6-4/0 #MO2-V stud meter socket

• Pad mount

• Direct earth burial style

• Load side splitter (add suffix ‘-SPL’)

Notes

• Service entrance rated main circuit breaker has neutral with service entrance bonding provision and ground lug

• 600V can be used for 480V & 208V systems

• 208V & 240V systems use QJ MCB

• Check if cold or hot metered and wire meter socket & MCB accordingly

• Always consult utility & local inspection authority for approval prior to ordering

• CEC allows only 240V 1 phase & 208V 3 phase to be cold metered

• Standard MCB is a Siemens ‘QJ’ Series, Cutler Hammer ‘ED’ or ‘EHD’ Series

• Are field interchangeable or optional at time of order
